Description:

Scag’s cutter decks have always given our competition a serious case of deck envy. Many try to duplicate the performance, but none can match it. The Velocity Plus™ cutter deck is an outstanding performer and delivers beautiful results.

Scag’s Velocity Plus™ Cutter Deck provides the unmatched power, precision and performance professionals’ demand. This revolutionary deck design delivers high-velocity discharge plus a beautiful, manicured cut, even at faster ground speeds. A redesigned cutting chamber and massive discharge opening provide even greater cutting performance with maximum clipping dispersal in any conditions.

Features:

• Strength — Scag’s tough cutter-blade spindles and Tri-Plate construction ensure solid performance and long life. A replaceable trim-side wear pad protects deck from damage.
• Productivity — An extra-large discharge opening, paired with the Turbo Baffle, enhances discharge for even clipping dispersal.
• Flexibility — The Velocity Plus cuts everything from fine grasses to tough weeds. The Custom-Cut™ Front Baffle System allows you to customize the deck to your individual conditions for even more productivity and higher performance.

Specifications:

General

• Total Fuel Capacity: 9.5 gallons
• Drive Tires: 24" x 9.5"-12"
• Caster Tires: 13" x 6.5"-6" (flat-free)
• Seat: 4-point iso-mounted mid-back mounted on operator-suspension platform

Drive System

• Drive System Type: Dual Pump and Motor
• Pumps (Hydro-Gear): 12 cc
• Motors (Parker): 14.5 ci
• Forward Ground Speed: 12 mph
• Reverse Ground Speed: 5 mph
• Parking Brake: Foot-operated pedal

Deck

• Cutting Width: 52"
• Type: Velocity Plus™
• Cutting Height: 1.5" to 5" in .25" increments
• Deck Lift: Foot-operated pedal
• Construction: Tri-plate cutter deck made of 3 steel plates totaling nearly 1/2" thick. Reinforcement plates at cutter deck spindles.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement: Ogura GT3.5 (250 ft-lb) with adjustable air-gap for extended life.

Product Dimensions

• Length: 80"
• Width (chute down): 64.5"
• Width (chute in transport position): 53.75"
• Height (ROPS Folded): 46.75"
• Height (ROPS Up): 67.25"
• Weight: 1175-1180 lbs
